DS-3WR4G3N 300Mbps 4G LTE Wi-Fi Router

Reliable, High-Speed Wireless Connectivity Anywhere

The DS-3WR4G3N 300Mbps 4G LTE Wi-Fi Router is designed to provide fast, stable, and flexible internet connectivity for both home and small office environments. Combining advanced 4G LTE capabilities with seamless Wi-Fi performance, this compact router delivers high-speed internet access wherever mobile networks are available. Its user-friendly design, multiple network modes, and robust security features make it an ideal solution for anyone looking to stay connected without relying on fixed broadband connections.

Compact and User-Friendly Design

The router features a sleek and compact form factor with dimensions of 126mm × 97mm × 42mm, making it suitable for desktop installation in a variety of environments. Its lightweight design (0.365 kg net weight) ensures portability, while the thoughtfully designed LED indicators provide real-time feedback on network status, Wi-Fi activity, LAN connections, and 4G/3G signal strength. The package includes a 4G LTE Router, power adapter, Ethernet cable, Quick Start Guide, and Regulatory Compliance information, ensuring an easy setup experience.

Robust Operating Conditions

The DS-3WR4G3N is built to function reliably under a wide range of conditions. It operates within a temperature range of 0°C to 40°C (32°F to 104°F) and humidity levels of 10% to 90% RH non-condensing. For storage, it can safely withstand temperatures between -40°C to 70°C (-40°F to 158°F) and humidity of 5% to 90% RH non-condensing, ensuring durability and stable performance over time. The router consumes a maximum of 6 W of power, making it energy-efficient for continuous operation.

Advanced Wireless Performance

The DS-3WR4G3N supports 2.4 GHz Wi-Fi with a maximum transmission rate of 300 Mbps, based on the IEEE 802.11b/g/n standard. Its 2×2 MIMO technology enhances signal quality and range, ensuring stable connectivity even in challenging environments. The router features two internal Wi-Fi antennas and two external 4G/3G antennas, delivering strong signal coverage for multiple devices simultaneously.

The router’s receiving sensitivity allows it to maintain reliable connections across various data rates:

• 2.4 GHz: -86 ±2dBm @ N20-MCS0 to -66 ±2dBm @ N20-MCS7
• 40 MHz bandwidth: -83 ±2dBm @ N40-MCS0 to -64 ±2dBm @ N40-MCS7
• Legacy Wi-Fi: -92 ±2dBm @ B-1M, -83 ±2dBm @ B-11M, -88 ±2dBm @ G-6M, -71 ±2dBm @ G-54M

This ensures reliable connectivity for video streaming, gaming, online meetings, and daily internet use.

Comprehensive Network Compatibility

The DS-3WR4G3N supports LTE CAT.4, with 4G download speeds of up to 150 Mbps and upload speeds of up to 50 Mbps. It is compatible with FDD LTE (B1/B3/B5/B7/B8/B20/B28AB), TDD LTE (B38/B40/B41), and WCDMA (B1/B5/B8) networks, making it versatile for use across multiple carriers.

The router also includes:

• Two RJ45 Ethernet ports with 10/100 Mbps auto-negotiation
• Nano SIM card slot for mobile network access
• LED indicators for internet connectivity, Wi-Fi, LAN, and 4G/3G signal strength
• WPS/Reset button for easy network configuration and troubleshooting

Flexible Application and Modes

This router offers multiple operational modes to meet different network needs:

• 3G/4G Route Mode for mobile broadband access
• Wireless Router Mode to extend Wi-Fi networks
• AP Mode for integration with existing wired networks

Additional application features include DHCP server support, guest network configuration, signal adjustment, Wi-Fi scheduling, and remote management through web interfaces.

Robust Security Features

The DS-3WR4G3N provides comprehensive security for home and office networks. It supports WPA-PSK, WPA2-PSK, WPA, and WPA2 encryption standards, ensuring safe communication over wireless networks. Users can also hide the SSID to prevent unauthorized access and manage their networks efficiently using the router’s web-based management interface, including firmware upgrades and system logs.

Conclusion

The DS-3WR4G3N 300Mbps 4G LTE Wi-Fi Router is a versatile, high-performance networking device that combines fast 4G LTE connectivity with reliable Wi-Fi performance. Its compact design, robust operating range, multiple network modes, and advanced security features make it ideal for both home and small office use. Whether you need a stable mobile internet solution or an extension to your existing network, the DS-3WR4G3N delivers seamless, high-speed connectivity wherever you go.
